Matrix RADIX S Wood Shafts

Overview

The Radix S is follow up structure to the successful line of shafts introduced in2011.
RADIX is Latin for “base” or “root”. The base for RADIX is The HD design, giving RADIX the most advanced internal structure in its class. Along with the internal structure, an experimental variable tip-to-butt ratio design is introduced with RADIX. The ratio specs change by flex – ball flight lowers as flex stiffens, adjusting for the progressive needs of progressively harder swingers.

Specifications

RADIX S-4

Flex	Length	Weight	Torque	Tip O.D	Butt O.D	Tip (Parallel)	Launch	Spin
A	46″	47g	5.3°	0.335	0.610	4.0	MID/HIGH	MID/HIGH
R	46″	48g	5.3°	0.335	0.610	4.0	MID/HIGH	MID/HIGH
S	46″	50g	5.3°	0.335	0.610	4.0	MID/HIGH	MID/HIGH

RADIX S-5

Flex	Length	Weight	Torque	Tip O.D	Butt O.D	Tip (Parallel)	Launch	Spin
A	46″	52g	5.0°	0.335	0.630	4.0	MID/HIGH	MID/HIGH
R	46″	53g	5.0°	0.335	0.630	4.0	MID/HIGH	MID/HIGH
S	46″	55g	5.0°	0.335	0.635	4.0	MID/HIGH	MID/HIGH
X	46″	58g	5.0°	0.335	0.635	4.0	MID/HIGH	MID/HIGH

RADIX S-6

Flex	Length	Weight	Torque	Tip O.D	Butt O.D	Tip (Parallel)	Launch	Spin
A	46″	58g	4.5°	0.335	0.640	4.0	MID/HIGH	MID/HIGH
R	46″	61g	4.5°	0.335	0.640	4.0	MID/HIGH	MID/HIGH
S	46″	63g	4.5°	0.335	0.640	4.0	MID/HIGH	MID/HIGH
X	46″	66g	4.5°	0.335	0.645	4.0	MID/HIGH	MID/HIGH

RADIX S-7

Flex	Length	Weight	Torque	Tip O.D	Butt O.D	Tip (Parallel)	Launch	Spin
R	46″	69g	4.0°	0.335	0.640	3.5	MID	HIGH
S	46″	71g	4.0°	0.335	0.645	3.5	MID	HIGH
X	46″	75g	4.0°	0.335	0.650	3.5	MID	HIGH
XX	46″	78g	4.0°	0.335	0.650	3.5	MID	HIGH

RADIX S-7321

Flex	Length	Weight	Torque	Tip O.D	Butt O.D	Tip (Parallel)	Launch	Spin
S	46″	73g	3.2°	0.335	0.630	4.5	MID	LOW/MID
X	46″	75g	3.2°	0.335	0.635	4.5	MID	LOW/MID
XX	46″	77g	3.2°	0.335	0.640	4.5	MID	LOW/MID
